Cnc Acrylic CO2 Laser Cutting/Laser Engraving Machine

Short Description:

UBO Acrylic Laser Cutting Machine UC-1390 is one type of CNC Laser Machine which is designed mainly for engraving and cutting work on material such as Acrylic, clothes, Fabric, papers, wood. Machine normally equipped with 60-200W laser tubes.The honeycomb or blade type holding table easy for good for heat radiation, Water chiller keeps the laser tube at normal temperature. Dust collecting device could suck all the smoke away during work. Our Acrylic Laser Cutting Machine for could cut up to 25 mm thickness acrylic sheet into different shape as designing request. Meanwhile ,Machine table could built to be automatic up and down with a rotary clamp attached for the cylinder material. Except for Acrylic, our Acrylic CNC Laser Engraving and Cutting Machine UC-1390 is also could be used for non-metal cutting such as Leather, Rubber, Plastic, shoes, clothes etc .


Product Detail

Product Tags

Product description

1. Hermetic and Detached CO2 Glass Laser Tube

10000h long lifetime,we can choose the suitable laser tube power according to different processing material thickness.

2. Honeycomb Working Table For Your Option

Especially for fabric engraving which can absorb the fabric firmly.

3. Thicken Strip Working Table For Your Option

Specially used for cutting and for heavy and hard products such as acrylic, PVC board cutting.

4. Customized Double Working Table

Design for your different material engraving and cutting requirements.

5. Taiwan Imported high precision Linear Guide Rail and Ball Screw Rod

High speed and accuracy with lower noise & long life span. Helps laser head move smoothly and laser beam reflect with high accuracy.

6. Water Chiller with Alarm Protection

CW3000/CW-5000/CW-5200 Water Chiller with temperature display, which can avoid over burning, to protect the water circulation from electricity-off.

7. Reflector Mirror Holder

Focal length adjusting Parts easy to find the center of the lens and find the right focal distance.

8. Rotary Fixture

Rotary Fixture is for the circle engraving of cylindrical or column work pieces. Need working together with Motorized Up and Down System.

Application

1) Foam processing of automotive stamping dies, casting of wood molds, automotive interiors, engineering plastic materials, and various non-metal processing

2) Furniture: wooden doors, cabinets, plate, office and wood furniture, tables, chair, doors and windows.

3) Wood mold processing center: Casting wood mold, automotive inspection tool processing, automotive interiors, engineering plastic materials and other non-metallic processing.

Main Configuration

Model UC-1390 UC-1610 UC-1325
Working Area 1300×900mm 1600×1000mm  1300×2500mm
Laser Power 60W / 80W / 100W / 120W / 150W
Laser Type Hermetic and Detached Co2 Laser Tube
Engraving Speed 1-60000mm/min
Cutting Speed 1-10000mm/min
Repeat Location Accuracy ± 0.0125mm
Laser Power Controlling 1-100% Manual Adjustment and Software Controlling
Voltage 220V(±10%) 50Hz
Cooling Mode Water Cooling and Protect System
Cutting Platform Professional Thickening Strip or Honeycomb Work Table
Controlling Mode CNC Professional Control System
Support Graphics Formats BMP, HPGL, JPEG, GIF, TIFF, PCX, TAG, CDR, DWG, DXF Compatible HPG Order To Support DXF, WMF, BMP, DXT
Power Controlling Mode Laser Energy Combining Movement Control System
Control Software Original Perfect Laser Engraving & Cutting Software

Our service

1. service before sales: our sales will communicate with you to know your requirements about the cnc router specification and what kind of work you will do, then we will offer our best solution for you. So that it can confirm each customer get their real needed machine.
2. service during production: we will send photos during manufacturing, so customers can know more details about the procession of making their machines and give their suggestions.
3. service before shipping: we will take photos and confirm with customers the specifications of their orders to avoid the mistake of wrong making machines.
4. service after shipping: we will write to customers in time when the machine departs, so customers can make enough preparation for the machine.
5. service after arrival: we will confirm with customers if machine is in good condition, and see if there is any spare part missing.
6. service of teaching: there are some manual and videos about how to use machine. If some customers have further question about it, we have professional technician to help install and teach how to use through Skype, calling, video, mail or remote control, etc.
7. service of warranty: we offer 12 month warranty for whole machine. If any fault of the machine parts within warranty period, we will replace it for free.
8. service in long-term: we hope every customer can use our machine easily and enjoy using it. If customers have any problems of machine in 3 or more years, please contact us freely.

Main parts

150

150W laser tube, able to engrave and cut most non-metals, such as acrylic, Perspex, rubber, leather, cloth, wood, glass, stone, ceramic, pvc, and metal, such as stainless steel, carbon steel, etc

Main electronic component in control box

Main electronic
32312

Rdcam control system

More useful and Humanized design

Rdcam control system

More useful and Humanized design

Water Cooling
Laser head
Laser head2

Rdcam control system

More useful and Humanized design

Square guide Rail made in Taiwan (PMI/HIWIN)

r322
High accuracy3

High accuracy drivers and stepper motors

Powerful Air pump for Blow to prevent excessive laser burning

Powerful Air
550W exhaust fan

550W exhaust fan, removes smoke and dust, protects optical parts and the users

Honeycomb table
Honeycomb table2

Honeycomb tablemain for engraving ,if you all work do engraving work ,so choose this kind table is ok.

Blade table:if you main do cutting ,choose this kind table will be better.

If you both do engraving and cutting ,half and half ,of course ,can choose both kind table.

Tool box and CD
Tool box and CD2

Tool box and CD

Make product display

1
21
31

FAQ

Q1. How to get the most suitable machine and best price

Please tell us the material you want to engrave or cut? Max size and thickness?

Q2. If we don't know how to use the machine,can you teach us?

Yes, we will, English manual and video will come along with the machine. You also can contact our service team if you need any help during use our machines.

Q3. How about your after-sales service?

we offer you 24 hours service by phone, Skype or Whatsapp.

Q4. Quality Control:

The whole production procedure will be under regular inspection and strict quality control. The complete machine will be tested to make sure they can work very well before being out of factory.

Our machine passed CE Certificate, meet European and American standard, were exported to more than 100 Countries.

Q5. How we pay you?

A. Consult us about this product on line or by e-mail.

B. Negotiate and confirm the final price , shipping , payment methods and other terms.

C. Send you the proforma invoice and confirm your order.

D. Make the payment according to the method put on proforma invoice.

E. We prepare for your order in terms of the proforma invoice after confirming your full payment. And 100% quality check before shipping.

F. Send your order by air or by sea.
