Automatic Tool Changer Cnc Wood Router Carving Cutting Machine

Short Description:

Economical CNC automatic tool change equipment. This model is practical for welding and forming thick square tubes and environmentally friendly spraying technology, which not only makes the machine beautiful, but also prolongs the life of the machine.

The advanced numerical control system can not only complete the existing work more efficiently, but also is a more economical and practical equipment.


Product Detail

Product Tags

Feature Of Machine

1. With hard steel structure, fit for hard wood working, like cutting and engraving on rosewood for furniture, indoor decoration.
2. With the Vacuum holding way and dust collector, the machine is qualified for mass-producing of furniture.
3. We use the best quality parts for the woodworking cnc router .
4. The machine's body is strong, rigid, high precision, reliable and durable.
5. Imported high precision ball screw gap, smooth movement, to ensure that the machine tools high-precision.
6. Well known domestic brands of water cooling brushless spindle, low noise, strong cutting ability, to ensure the long time working.
7. High-performance driven motor to ensure that the woodworking cnc router high speed and accuracy.
8. Designer perfectly, select the best machine accessories, to minimize the failure rate preferred.

Application

1.Woodworking Industry: MDF, wood, acrylic, PVC, double-color board, brass, aluminum, marble, crystal.

2. Advertising industry: advertising billboard, sign making, acrylic cutting, graphic mold forming and processing of many kinds of advertising terms.

3. Architectural model industry: metal models of copper, aluminum, iron etc, and non-metal models, such as artificial marble, grave, plastic board, PVC, board etc.

4. Other industry: image engraving, embossing, craft and gift industry.

Main Configuration

Model UW-A1325L
Working Area 1300*2500*200mm
Spindle Type water cooling spindle
Spindle Power 9.0KW Chinese ATC
Spindle Rotating Speed 0-24000rpm
Power (except spindle power) 5.8KW (include powers of: motors, drivers, inverters and so on)
Power Supply AC380/220v±10,  50 HZ
Worktable Vacuum Table and T-slot
Driving Syestm Japanses Yaskawa servo motors and drivers
Transmission X,Y :Gear rack, high accuracy square guide rail,
Z: ball screw TBI and hiwin square guide rail
Locating precision <0.01mm
Min Shaping Character Character:2x2mm,letter:1x1mm
Operating Temperature 5°C-40°C
Working Humidity 30%-75%
Working Precision ±0.03mm
System Resolution ±0.001mm
Control Configuration Mach3
Data Transfer Interface USB
System Environment Windows 7/8/10
Spindle Cooling Way Water cooling by water chiller
Limited Switch High sensitivity limited switches
Graphic Format Supported G code: *.u00, * mmg, * plt, *.nc
Compatible Software ARTCAM, UCANCAM ,Type3 and other CAD or CAM softwares….

Service

1. From chosen to shipping:
our sales will communicate with you to know your requirements about the cnc router specification and what kind of work you will do, then we will offer our best solution for you. So that it can confirm each customer get their real needed machine.
Then we will send photos during manufacturing, so customers can know more details about the procession of making their machines and give their suggestions.
at last start shipping, we will take photos and confirm with customers the specifications of their orders to avoid the mistake of wrong making machines.
2. After shipping to arrival to customer:
we have write packing list with machine, after you open package m,then can check everything according the list,so customers can make enough preparation for the machine.
Please also first learn the manual of the cnc, there are some manual and videos about how to use machine. If some customers have further question about it, we have professional technician to help install and teach how to use through Skype, calling, video, mail or remote control, etc.
Long time warranty for whole machine. If any fault of the machine parts within warranty period, we will replace it for free.
Whole life service for machine:if any problems can contact us freely.

FAQ

Q1: How can we get the suitable machine with best price?

A:As you may know,the different type of CNC machine apply to the different material,and the different model apply to the different material. Please first tell me your real requirements,then help you choose the suitable machine.then according the configurations offer you the competitive price.
Please tell me what’s material you want to cutting or engraving ?

Q2: what's MAX size of carved material?

A: Then I wil recommand the most suitable model and the best price for you.

Q3: In case of failure, how to do?

A:Call us----our enginners are online for 24-hours,and ready to serve you.
Replacement of damaged parts for free---For more information,please contact us
The CD and operation manual----It show the most common failure in working processing and how to solve this problems.

Q4: Are you trading company or manufacturer?

A: Yes,We are factory with more than 10 years experience.

Q5: How long is your delivery time?

A: Generally it is one week days if the goods are in stock. or it is 15 working days if the goods are not in stock, it is according to quantity.
